| Product Style |
Clamshell |
|
| LCD |
Size |
16"(16:10),EDP LED |
EDP LED |
| Resolution Support |
2560*1600(2.5K) |
|
| Touch Panel |
Interface type |
NA |
|
| Physical parameter |
Material |
A/D Metal,B/C plastic |
|
| Hinge open angle |
165 |
|
| Kensington Lock |
yes |
|
| Weight |
<2.4kg |
|
| Dimensional |
359*260*22.1 mm |
|
| I/O Port |
MB Side |
|
| USB Type_A |
2*USB3.2 Gen2 |
Side |
| USB Type_C |
1*USB4(Data+DP)+1*USB3.2 Gen1(Data+DP) |
Rear |
| HDMI |
1*HDMI 2.0 |
| RJ45 |
10M/100M/1000M/2500M |
| DC Jack |
Ø5.8mm (2.5mm) |
| DB Side |
|
| Audio Jack |
Ø3.5mm Combo |
|
| Cardreader |
3 in 1 card reader |
|
| Indicated light |
Charge LED |
Red LED for charging
Blue LED for full charged |
the side of DC Jack |
| Power LED |
red LED for Performance mode
yellow LED for Balanced mode
green LED for Quiet mode |
in the Power key |
| Caps Lock LED |
White LED |
Caps Lock on the KB |
| Num Lock LED |
White LED |
Num Lock on the KB |
| Key |
Voice +/- |
NA |
|
| Power Key |
on C Cover |
|
| Key board |
Back light |
Support, RGB(optional) |
|
| Matrix |
US/UK |
|
| Web Camera |
Front |
2M, USB |
|
| Rear |
N/A |
|
| Touch Pad |
type |
All-in-one |
|
| Fingerprint |
location |
On powerkey or touchpad |
Option |
| Battery Capacity |
Li-polymer Battery,4S1P/15.4V, 4800mAh , 74WH |
|
| Hardware |
| CPU |
Type |
AMD® Rembrandt H & Rembrandt+ H (FP7r2) |
TDP 45W (sTTP 54W) |
| GPU |
Type |
AMD® Discrete Graphics |
eDP supports automatic switching of dGPU/iGPU display output |
| Type |
(1) Navi23 XTM+(R22M-E100-65), 32CU;Bus lane: x8;Width 128bit
(2) Navi23XM(R22M-E65-75), 28CU;Bus lane: x8;Width 128bit |
cTGP : 80W-120W / cTGP : 50W-100W |
| Display Memory |
GDDR6/8GB, 4 channel*16Gb(IO Data rate), speed 16Gbps, 180 Balls |
|
| Chipset |
Type |
N/A |
|
| Storage |
RAM |
DDR5-4800MHz ; 2*SO-DIMM |
Up to 32GBb; PHX support clock-rate 5600MHz |
| ROM (eMMC) |
N/A |
|
| SSD |
2*M.2 2280(Default SSD1) |
SSD1 PCIE Gen4/SATA, SSD2 PCIE Gen4/SATA; SATA support by Rembrandt & only |
| HDD |
NA |
|
| Extended Storage |
Support |
|
| Audio |
Codec |
CX11880 |
|
| Speaker |
2*42W |
|
| MIC |
2*D-MIC, Support Cortana |
|
| Sensor |
Hall Sensor |
Support |
|
| TPM |
Interface type |
Option |
|
| RTC |
RTC Connector |
Yes |
|
| Others |
|
| Network Connections |
| WIFI |
WIFI chip model |
M.2 2230 PCIe |
|
| WIFI Standard |
Support WiFi 802.11b/g/n/ac/ax, 2*2 MIMO |
|
| WIFI Frequency |
2.4G/5G/6G |
Wifi 6E |
| Bluetooth |
Bluetooth |
Support |
|
| Version |
4.2/5.1 |
|
| LTE |
4G LTE |
NA |
|
| Ethernet |
Gigabit Lan |
Yes |
100M/1000M/2500M |
| Modern Standby |
Support or not |
YES |
|
| Software |
| OS |
System |
Windows 11/ Linux |
|
| Bluetooth PLDR(Platform Level Device Reset) |
Support |
| Language Supported |
Support multi-language |
|
| BIOS/EC |
UI spec |
Clover customization |
|
AMD
Advantage Technology |
Smart Shift Max |
Support |
|
| Smart Shift Eco(Graphic S/W) |
Support |
|
| Smart Access Memory |
Support |
|
| Smart CASO |
Support |
|
| Smart Access Graphics(Smart Mux) |
Support |
|
| Hot Key |
Fn+Esc |
Sleep |
|
| Fn+F1 |
Working Mode Switch:Performance mode/Balanced mode/Quiet mode |
|
| Fn+F2 |
Mute |
|
| Fn+F3 |
Vol + |
|
| Fn+F4 |
Vol - |
|
| Fn+F5 |
MIC On/Off |
|
| Fn+F6 |
Screen Brightness + |
|
| Fn+F7 |
Screen Brightness - |
|
| Fn+F8 |
Screen On/Off |
|
| Fn+F9 |
Flight Mode On/Off |
|
| Fn+F10 |
Touchpad On/Off |
|
| Fn+F11 |
Projection Mode Switch |
Projection mode |
| Fn+F12 |
Ambient Light On/Off |
|
| Fn+Space Bar |
Keyboard Backlight Brightness2/Brightness1/Off |
|
| Standard Accessories |
| Adaptor |
INPUT |
AC 100~240V |
|
| OUTPUT |
230W ,19.5V/11.79A |
|
