| Product Style |
Convertible |
|
|
| LCD |
Size |
14.0"(16:9),EDP |
|
|
| Resolution Support |
HD/FHD |
|
|
| Touch Panel |
Support or not |
Yes |
|
|
| Physical parameter |
Material |
A/D Metal,B Glass,C Plastic |
|
|
| Hinge open angle |
360 |
|
|
| Kensington Lock |
NA |
|
|
| Weight |
1.4Kg |
|
|
| Dimension |
217*323*16.3mm |
|
|
| I/O Port |
MB Side |
|
|
| DC Jack |
Ø3.5*1.35mm |
|
|
| USB Type_C |
1*Data(USB3.2 Gen1)+PD+DP |
|
|
| DB Side |
|
|
| Audio Jack |
Ø3.5mm Combo |
|
|
| Cardreader |
1*Micro SD |
|
|
| 1*SIM (Optional) |
|
|
| USB Type_A |
1*USB3.2 Gen1 |
|
|
| Indicated light |
Power LED |
Blue LED |
Top left of C case |
|
| Caps Lock |
Blue LED |
|
| Num Lock |
Blue LED |
|
| Key |
Voice +/- |
NA |
|
|
| Power Key |
Right of C Case |
|
|
| Key board |
Back light |
Support |
|
|
| Matrix |
US/UK |
|
|
| Web Camera |
Front |
1M |
|
|
| Rear |
N/A |
|
|
| Touch Pad |
type |
All-in-one |
|
|
| Fingerprint |
Location |
Touchpad |
Optional |
|
| Hardware |
|
| CPU |
Type |
i5-1135G7 I5-1235U |
Up to 15W |
| GPU |
Type |
Intel UHD Graphics/Intel Iris Xe Graphics |
|
|
| Storage |
RAM |
2*LPDDR4X-556/366ball |
|
|
| ROM (eMMC/UFS) |
NA |
|
|
| SSD |
1*M.2 2280 PCIe3.0 X4/SATA Auto |
|
|
| HDD |
NA |
|
|
| Extended Storage |
1*SD3.0 |
|
|
| Battery |
Type |
Li-polymer Battery |
|
|
| Voltage |
7.6V, 6000 mAh, 45.6Wh |
|
|
| Audio |
Speaker |
8 1W *2 or 4 2W *2 |
|
|
| Codec |
Realtek_ALC255-256-282-283CG/ES8336/ES8336D colay |
|
|
| MIC |
1*D-MIC in Camera Module |
|
|
| TPM |
Interface type |
SPI |
FTPM or DTPM option |
|
| vPro |
Type |
NA |
|
|
| RTC |
RTC Connector |
Option |
|
|
| Others |
|
|
|
| Network Connections |
|
| WIFI |
WIFI chip model |
PCIe&CNVi Onboard |
|
|
| WIFI Standard |
Support WiFi 802.11b/g/n/ac/ax(wifi6) |
|
|
| WIFI Frequency |
2.4G/5G |
|
|
| LTE |
4G LTE |
Optional |
|
|
| Ethernet |
Gigabit Lan |
NA |
|
|
| Modern Standby |
Support or not |
NA |
|
|
| Software |
|
| OS |
System |
Windows 11/ Linux |
|
|
| Language Supported |
Support multi-language |
|
|
| BIOS/EC |
UI spec |
Clover customization |
|
|
| Standard Accessories |
|
| Adaptor |
INPUT |
AC 100~240V |
|
|
| OUTPUT |
19V,2.1A, 40W |
|
|
| Approval |
|
